X1 HIGH BAY MS MODULE
Automatically control lighting based on occupancy.
- Remote Sensor Programming [XCHBAREM sold separately]
Quick configuration of X1 High Bay sensor settings from floor level, with an operating range of up to 15m - Simple, Plug & Play Installation
Zhaga base connection - Scene Setting
Detection area, hold time, standby dim level, standby period - Detection Area
8m radius, 15m maximum installation height, detection angle of 30° to 150° - Detection Sensitivity
Adjusts the detection sensitivity according to the installation height, or by the selectable values 25%,50%,75% or 100% - Corridor Function
After the hold time expires, the sensor dims the brightness to the standby level and time required - Brightness Adjustable
From 10% up to 100%, in 5% increments
